La linea - 5mt - SMD

IP65

Downloadable files

Silhouette
  • La Linea SMD.jpg
Instructions
  • Y513001641B F_IS LA LINEA SMD KIT.pdf
  • Y513001723B F_IS LA LINEA KIT SMD J-BOX.pdf
  • Y513001748 FOGLIO ISTRUZ LA LINEA SMD.pdf
IES Europe
  • T4600510.IES
  • T4600510_1000mm.IES
  • T4600510_500mm.IES
IES USA
  • T4600510.IES
  • T4600510_1000mm.IES
  • T4600510_500mm.IES
LDT File
  • T4600510.LDT
  • T4600510_1000mm.LDT
  • T4600510_500mm.LDT
LDT PDF
  • T4600510.PDF
  • T4600510_1000MM.PDF
  • T4600510_500MM.PDF
FEATURES
  • Product Code: T4600510
  • Colour: White
  • Installation: Ceiling, Wall
  • Material: High diffusion optical silicone lamp body. Transparent technopolymer wall mounts. Steel recessed ceiling mounts, steel and aluminum surface-mounted ceiling mounts.
  • Series: Design Collection, Architectural Outdoor
  • design by: BIG - Bjarke Ingels Group
LUMINAIRE
  • Watt: 15W/m
  • Delivered lumen output: 960 lm/m
  • CCT: 3000K
  • Efficiency: 100%
  • Efficacy: 64lm/W
  • CRI: 95
DIMENSIONS
  • Length: 5000 mm
  • Diameter: 40 mm
AWARDS

Winner of the Archiproducts Design Awards 2019 - Lighting Category
Winner of Wallpapers Design Awards 2020
Winner of Bo Bedre Design Awards 2020 - Lighting Category
Winner of NYCxDESIGN Awards 2021
Compasso d'Oro Award, Honourable Mention

Notes

10 wall/ceiling supports included

Weight 1,4 kg/m

Driver included

Accessories
Additional wall/ceiling support
R304975
