Calipso Linear System 60 Ceiling

IP20 Dimmbar:

Downloadable files

3D Model
  • CALIPSO LINEAR SYS 60 CEILING.3ds
  • CALIPSO LINEAR SYS 60 CEILING.stp
  • CALIPSO LINEAR SYS CEILING ACCESSORIES.zip
  • CALIPSO LINEAR SYS CEILING EXAMPLE CONFIGURATION.3ds
  • CALIPSO LINEAR SYS CEILING EXAMPLE CONFIGURATION.stp
Silhouette
  • CALIPSO_System_C_60.jpg
Instructions
  • Y513001106B_Calipso Linear System Soffitto.pdf
3D BIM Revit
  • Artemide Calipso System EN.zip
  • Artemide Calipso System EN_Low Version.zip
IES Europe
  • 2010010A.IES
IES USA
  • 2010010A.IES
LDT File
  • 2010010A.LDT
LDT PDF
  • 2010010A.PDF
FUNKTIONEN
  • Produktcode: 2010010A
  • Farbe: White
  • Installation: Deckenleuchte
  • Material: Technopolymer, aluminium
  • Serie: Design Collection, Architectural Indoor
  • Anwendungsbereich: Innenbeleuchtung
  • design: Neil Poulton
LUMINAIRE
  • Watt: 22W
  • Lichtstrom (lm): 1492lm
  • CCT: 3000K
  • Efficiency: 58%
  • Efficacy: 67.84lm/W
  • CRI: 90
  • Dimmable Typology: Push/DALI
DIMENSION
  • Länge: 588 mm
  • Breite: 79 mm
  • Höhe: 72 mm
INKLUSIVE LICHTQUELLEN
  • Kategorie: Led
  • Anzahl: 1
  • Watt: 19,4W
  • Lichtstrom (lm): 2400lm
  • Farbtemperatur(K): 3000K
  • CRI: 90
  • Efficacy: 124lm/W
  • Service Life: 50000-L70
Anmerkungen

APP driver can not be controlled by a DALI dimming/Push system and viceversa.

In any APP configurations there must be only one App module (master) while the others must be DALI.

ZUBEHÖR
Intermediate linear joint - Ceiling - It allows to mechanically connect two modules in-line
2025010A
End cap kit - Ceiling (2 pcs)
2026010A
Joint 90° kit - Ceiling (dx+sx) - It allows to mechanically connect two modules at 90°
2027010A
