Nur Mini Gloss LED - Suspension - Black

IP20/40 Dimmerable:

Downloadable files

2D Model
  • Nur_Gloss_mini_sospensione.dwg
  • Nur_Gloss_mini_sospensione.dxf
3D Model
  • Nur_Gloss_mini_sospensione.3ds
  • Nur_Gloss_mini_sospensione.stp
Silhouette
  • Nur-Mini-Gloss.jpg
Instructions
  • Y513000179B F_IS NUR MINI LED SUSPENSION.pdf
IES Europe
  • A246410.IES
IES USA
  • A246410.IES
LDT File
  • A246410.LDT
LDT PDF
  • A246410.PDF
FEATURES
  • Product Code: A246410
  • Colour: Black
  • Installation: Suspension
  • Material: Aluminum, methacrylate, glass
  • Series: Design Collection
  • Environment: Indoor
  • Area contract: Hospitality, Residential
  • Emission: Direct/indirect
  • design by: Ernesto Gismondi
LUMINAIRE
  • Watt: 30W
  • Voltage: 220V-240V
  • Delivered lumen output: 1287lm
  • CCT: 2700K
  • Efficiency: 47%
  • Efficacy: 42.90lm/W
  • CRI: 90
  • Dimmable Typology: Push
DIMENSIONS
  • Height: 285 mm
  • Diameter: 360 mm
  • Base Diameter: 180 mm
  • Max Height from ceiling: 2200 mm
  • Glow Wire Test: 650°C
SOURCES INCLUDED
  • Category: Led
  • Number: 1
  • Watt: 30W
  • Delivered lumen output: 2990lm
  • Color temperature (K): 2700K
  • CRI: 90
  • Color Tolerance: MacAdam 2SDCM
Notes

All the versions are encased in a diffuser at the bottom.

Download all Data sheet PDF
