Series
Y

“DIVORCE LIGHTING FROM THE CEILING. Series Y creates a soft dialogue with the space it illuminates. It is the intersection between complexity and simplicity, functionality and aesthetic. It solves real issues in the workplace like the needs of more uneven compositions and unexpected, open or closed,
geometries”.   Gensler

Product overview

emission

distribution

colour

watt

delivered lumens output

cct

dimmer

Technical characteristics
Product name Code Watt Lm CCT Colour Save
Series Y - Diffuse Direct Emission - 3000K - Undimmable - Black Series Y - Diffuse Direct Emission - 3000K - Undimmable - Black AY00004 35W 2940lm 3000K
Series Y - Diffuse Direct Emission - 3000K - Undimmable - Silver Series Y - Diffuse Direct Emission - 3000K - Undimmable - Silver AY00005 35W 2940lm 3000K
Series Y - Diffuse Direct Emission - 3000K - Undimmable - White Series Y - Diffuse Direct Emission - 3000K - Undimmable - White AY00001 35W 2940lm 3000K
Series Y - Diffuse Direct Emission - 4000K - Undimmable - Black Series Y - Diffuse Direct Emission - 4000K - Undimmable - Black AY00504 35W 3095lm 4000K
Series Y - Diffuse Direct Emission - 4000K - Undimmable - Silver Series Y - Diffuse Direct Emission - 4000K - Undimmable - Silver AY00505 35W 3095lm 4000K
Series Y - Diffuse Direct Emission - 4000K - Undimmable - White Series Y - Diffuse Direct Emission - 4000K - Undimmable - White AY00501 35W 3095lm 4000K
Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 3000K - DALI - Black Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 3000K - DALI - Black AY05004 55W 4742lm 3000K
Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 3000K - DALI - Silver Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 3000K - DALI - Silver AY05005 55W 4742lm 3000K
Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 3000K - DALI - White Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 3000K - DALI - White AY05001 20W 1802lm 3000K
Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 4000K - DALI - Black Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 4000K - DALI - Black AY05504 55W 4992lm 4000K
Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 4000K - DALI - Silver Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 4000K - DALI - Silver AY05505 55W 4992lm 4000K
Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 4000K - DALI - White Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 4000K - DALI - White AY05501 20W 1897lm 4000K
Series Y - Controlled Direct Emission - 3000K - Undimmable - Black Series Y - Controlled Direct Emission - 3000K - Undimmable - Black AY01004 35W 2559lm 3000K
Series Y - Controlled Direct Emission - 3000K - Undimmable - Silver Series Y - Controlled Direct Emission - 3000K - Undimmable - Silver AY01005 35W 2559lm 3000K
Series Y - Controlled Direct Emission - 3000K - Undimmable - White Series Y - Controlled Direct Emission - 3000K - Undimmable - White AY01001 35W 2559lm 3000K
Series Y - Controlled Direct Emission - 4000K - Undimmable - Black Series Y - Controlled Direct Emission - 4000K - Undimmable - Black AY01504 35W 2694lm 4000K
Series Y - Controlled Direct Emission - 4000K - Undimmable - Silver Series Y - Controlled Direct Emission - 4000K - Undimmable - Silver AY01505 35W 2694lm 4000K
Series Y - Controlled Direct Emission - 4000K - Undimmable - White Series Y - Controlled Direct Emission - 4000K - Undimmable - White AY01501 35W 2694lm 4000K
Series Y - Controlled Direct Emission + Batwing Indirect Emission - 3000K - DALI - Black Series Y - Controlled Direct Emission + Batwing Indirect Emission - 3000K - DALI - Black AY06004 55W 4361lm 3000K
Series Y - Controlled Direct Emission + Batwing Indirect Emission - 3000K - DALI - Silver Series Y - Controlled Direct Emission + Batwing Indirect Emission - 3000K - DALI - Silver AY06005 55W 4361lm 3000K
Series Y - Controlled Direct Emission + Batwing Indirect Emission - 3000K - DALI - White Series Y - Controlled Direct Emission + Batwing Indirect Emission - 3000K - DALI - White AY06001 55W 4361lm 3000K
Series Y - Controlled Direct Emission + Batwing Indirect Emission - 4000K - DALI - Black Series Y - Controlled Direct Emission + Batwing Indirect Emission - 4000K - DALI - Black AY06504 55W 4591lm 4000K
Series Y - Controlled Direct Emission + Batwing Indirect Emission - 4000K - DALI - Silver Series Y - Controlled Direct Emission + Batwing Indirect Emission - 4000K - DALI - Silver AY06505 55W 4591lm 4000K
Series Y - Controlled Direct Emission + Batwing Indirect Emission - 4000K - DALI - White Series Y - Controlled Direct Emission + Batwing Indirect Emission - 4000K - DALI - White AY06501 55W 4591lm 4000K
Product name
Code
Watt
Lm
CCT
Colour
Save
Series Y - Diffuse Direct Emission - 3000K - Undimmable - Black
Series Y - Diffuse Direct Emission - 3000K - Undimmable - Black
35W
2940lm
3000K
Series Y - Diffuse Direct Emission - 3000K - Undimmable - Silver
Series Y - Diffuse Direct Emission - 3000K - Undimmable - Silver
35W
2940lm
3000K
Series Y - Diffuse Direct Emission - 3000K - Undimmable - White
Series Y - Diffuse Direct Emission - 3000K - Undimmable - White
35W
2940lm
3000K
Series Y - Diffuse Direct Emission - 4000K - Undimmable - Black
Series Y - Diffuse Direct Emission - 4000K - Undimmable - Black
35W
3095lm
4000K
Series Y - Diffuse Direct Emission - 4000K - Undimmable - Silver
Series Y - Diffuse Direct Emission - 4000K - Undimmable - Silver
35W
3095lm
4000K
Series Y - Diffuse Direct Emission - 4000K - Undimmable - White
Series Y - Diffuse Direct Emission - 4000K - Undimmable - White
35W
3095lm
4000K
Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 3000K - DALI - Black
Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 3000K - DALI - Black
55W
4742lm
3000K
Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 3000K - DALI - Silver
Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 3000K - DALI - Silver
55W
4742lm
3000K
Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 3000K - DALI - White
Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 3000K - DALI - White
20W
1802lm
3000K
Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 4000K - DALI - Black
Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 4000K - DALI - Black
55W
4992lm
4000K
Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 4000K - DALI - Silver
Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 4000K - DALI - Silver
55W
4992lm
4000K
Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 4000K - DALI - White
Series Y - Diffuse Direct Emission + Batwing Indirect Emission - 4000K - DALI - White
20W
1897lm
4000K
Series Y - Controlled Direct Emission - 3000K - Undimmable - Black
Series Y - Controlled Direct Emission - 3000K - Undimmable - Black
35W
2559lm
3000K
Series Y - Controlled Direct Emission - 3000K - Undimmable - Silver
Series Y - Controlled Direct Emission - 3000K - Undimmable - Silver
35W
2559lm
3000K
Series Y - Controlled Direct Emission - 3000K - Undimmable - White
Series Y - Controlled Direct Emission - 3000K - Undimmable - White
35W
2559lm
3000K
Series Y - Controlled Direct Emission - 4000K - Undimmable - Black
Series Y - Controlled Direct Emission - 4000K - Undimmable - Black
35W
2694lm
4000K
Series Y - Controlled Direct Emission - 4000K - Undimmable - Silver
Series Y - Controlled Direct Emission - 4000K - Undimmable - Silver
35W
2694lm
4000K
Series Y - Controlled Direct Emission - 4000K - Undimmable - White
Series Y - Controlled Direct Emission - 4000K - Undimmable - White
35W
2694lm
4000K
Series Y - Controlled Direct Emission + Batwing Indirect Emission - 3000K - DALI - Black
Series Y - Controlled Direct Emission + Batwing Indirect Emission - 3000K - DALI - Black
55W
4361lm
3000K
Series Y - Controlled Direct Emission + Batwing Indirect Emission - 3000K - DALI - Silver
Series Y - Controlled Direct Emission + Batwing Indirect Emission - 3000K - DALI - Silver
55W
4361lm
3000K
Series Y - Controlled Direct Emission + Batwing Indirect Emission - 3000K - DALI - White
Series Y - Controlled Direct Emission + Batwing Indirect Emission - 3000K - DALI - White
55W
4361lm
3000K
Series Y - Controlled Direct Emission + Batwing Indirect Emission - 4000K - DALI - Black
Series Y - Controlled Direct Emission + Batwing Indirect Emission - 4000K - DALI - Black
55W
4591lm
4000K
Series Y - Controlled Direct Emission + Batwing Indirect Emission - 4000K - DALI - Silver
Series Y - Controlled Direct Emission + Batwing Indirect Emission - 4000K - DALI - Silver
55W
4591lm
4000K
Series Y - Controlled Direct Emission + Batwing Indirect Emission - 4000K - DALI - White
Series Y - Controlled Direct Emission + Batwing Indirect Emission - 4000K - DALI - White
55W
4591lm
4000K

The colors represented in the 3D model above do not exactly match the real colors of the product. For further information please contact info@artemide.com
